Reliable Hydraulic Breaker For Excavator With Nitrogen 14-17 Bar
PF1/2 Inch Hose Size
Product Description:
Hydraulic Rock Breaker
This Hydraulic Rock Breaker is designed to break hard rocks quickly
and efficiently. It has an operation weight of 275 mm and a hose
size of PF1/2'' inch, which provides a high breaking power and
efficiency. It is suitable for use with a backhoe loader and can be
used for breaking rock. The flow rate of the oil is 40~70 L/min,
and it provides a steady and reliable performance. It is also easy
to use and comes with a 1 year warranty.
This Hydraulic Rock Breaker is ideal for any job that requires
breaking rock with a hydraulic hammer. It has a powerful breaking
power that makes it suitable for breaking hard rocks. It also
provides a reliable performance and is easy to use. This Hydraulic
Rock Hammer is perfect for any job that requires breaking rock with
a hydraulic hammer.
Our All Models Data
| Item | Unit | DSB53 | DSB68 | DSB75 | DSB85 | DSB100 | DSB135 | DSB140 | DSB150 | DSB155 | DSB165 | DSB175 | DSB180 |
Total Length
(WITH MOUNT CAP& TOOL) | SIDE TYPE | mm | 1,140 | 1,330 | 1,699 | 1,767 | 1,939 | 2,289 | 2,414 | 2,603 | 2,776 | 2,919 | 3,189 | 3,253 |
| OPEN TYPE | mm | 1,372 | 1,641 | 1,719 | 2,160 | 2,339 | 2,719 | 3,030 | 2,904 | 3,119 | 3,359 | 3,617 | 3,753 |
| BOX TYPE | mm | 1,400 | 1,658 | 1,741 | 2,200 | 2,400 | 2,766 | 3,075 | 3,075 | 3,250 | 3,450 | 3,711 | 3,760 |
Operation Weight
(WITH TOOL) | SIDE TYPE | kg | 137 | 281 | 398 | 618 | 845 | 1,605 | 1,812 | 2,530 | 2,752 | 3,189 | 4,055 | 4,586 |
| OPEN TYPE | kg | 132 | 275 | 390 | 604 | 920 | 1,784 | 1,975 | 2,750 | 2,818 | 3,514 | 4,370 | 4,600 |
| BOX TYPE | kg | 161 | 348 | 456 | 675 | 978 | 1,942 | 2,174 | 2,895 | 2,906 | 3,586 | 4,480 | 4,658 |
| Operation Pressure | kgf/cm2 | 90~120 | 110~140 | 120~150 | 130~160 | 140~170 | 160~180 | 160~180 | 160~180 | 160~180 | 160~180 | 160~200 | 180~220 |
| psi | 1,280~1,706 | 1,564~1,990 | 1,706~2,133 | 1,706~2,133 | 1,990~2,417 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,559~3,128 |
| Oil Flow | l/min | 25~45 | 40~70 | 50~90 | 60~100 | 80~120 | 120~150 | 120~150 | 170~240 | 170~240 | 190~250 | 220~260 | 220~260 |
| gpm | 6.6~11.9 | 7.9~13.2 | 13.2~23.8 | 15.8~26.4 | 21.1~31.7 | 31.7~39.6 | 31.7~39.6 | 44.9~63.4 | 44.9~63.4 | 50.1~66.0 | 58.1~76.5 | 58.1~76.5 |
| Impact Rate | bpm | 550~1000 | 450~950 | 400~900 | 400~800 | 450~630 | 350~500 | 250~400 | 380~480 | 320~450 | 280~370 | 240~320 | 210~300 |
| Nitrogen | bar | 14-17 | 14-17 | 14-17 | 14-17 | 14-17 | 14-17 | 14-17 | 18-22 | 17-20 | 17-20 | 22-25 | 22-25 |
| Chisel Diameter | mm | 53 | 68 | 75 | 85 | 100 | 135 | 140 | 150 | 155 | 165 | 175 | 185 |
| inch | 2.08 | 2.67 | 2.95 | 3.34 | 3.93 | 5.31 | 5.51 | 5.9 | 6.11 | 6.48 | 6.88 | 7.27 |
| Chisel Length | mm | 550 | 700 | 750 | 850 | 1,000 | 1,200 | 1,200 | 1,300 | 1,400 | 1,400 | 1,500 | 1,600 |
| Chisel Weight | kg | 9 | 18 | 29 | 32 | 57 | 121 | 137 | 170 | 193 | 227 | 272 | 320 |
| Hose Size | mm | 13 | 13 | 13 | 19 | 19 | 25 | 25 | 25 | 32 | 32 | 32 | 32 |
| inch | PF1/2'' | PF1/2'' | PF1/2'' | PF3/4'' | PF3/4'' | PF1'' | PF1'' | PF1'' | PF1-1/4'' | PF1-1/4'' | PF1-1/4'' | PF1-1/4'' |
| Noise Level | m | 4/8 | 5/10 | 6/12 | 6/12 | 7/14 | 16-22 | 16-22 | 26-35 | 26-35 | 35-40 | 38-45 | 42-48 |
| Suitable Exca | ton | 2.1~4.0 | 4.8~8.0 | 6.0~9.0 | 8.0~12.5 | 12~15 | 20~26 | 22~27 | 25-32 | 26~35 | 30~42 | 35~45 | 45~50 |
| Impact Force | j | 355 | 560 | 790 | 1320 | 1980 | 3450 | 3720 | 5250 | 5750 | 7040 | 14800 | 17550
|
Features:
- Product Name: Hydraulic Rock Breaker
- Operation Weight: 275 Mm
- Noise Level: 5-10 M
- Chisel Length: 700 Mm
- Oil Flow: 40~70 L/min
- Nitrogen: 14-17 Bar
- Backhoe Loader Hydraulic Breaker Hammer
- Hydraulic Rock Hammer
Technical Parameters:
| Parameter | Value |
|---|
| Impact Rate | 450~950 Bpm |
| Warranty | 1 Year |
| Model | Open Type |
| Hose Size | PF1/2'' Inch |
| Suitable Excavator | 4.8~8.0 Ton |
| Chisel Length | 700 Mm |
| Chisel Diameter | 68 Mm |
| Nitrogen | 14-17 Bar |
| Impact Force | 560 J |
| Oil Flow | 40~70 L/min |
Applications:
Hydraulic Rock Breakers are manufactured by DONSANNG, with a model
number of DSB135, and have been certified by CE and ISO 9001. They
are available in minimum order quantities of 1 and the price is
negotiable. The delivery time is 15 working days, with payment
terms also negotiable. The product is available in a standard
wooden box and supply ability is 100 sets per month. The noise
level is 5-10 M and they are suitable for excavators of 4.8-8.0
tons. The operation weight is 275 mm and the model is open type,
with the color customization options of white and blue.
DONSANNG Hydraulic Rock Breakers are a reliable and efficient
solution for breaking rock and minerals. The hydraulic hammer can
be used in a variety of applications, from road works and
demolition to mining and quarrying. The hydraulic breaker is
capable of breaking even the toughest rocks, making it an ideal
choice for mining and construction sites. With its advanced
engineering design, the hydraulic breaker is able to provide a
powerful and controlled force when used, making it a popular choice
for rock breaking.
DONSANNG Hydraulic Rock Breakers are an excellent choice for those
looking for a reliable and efficient hydraulic hammer solution.
With its advanced design and efficient performance, it is one of
the most trusted hydraulic rock breaker manufacturers in the
market. With its long-lasting and durable construction, it is sure
to provide a reliable and efficient breaking solution for all your
rock and mineral needs.
Customization:
Hydraulic Rock Breaker - DONSANG Brand, Model number: DSB135, Place of Origin: China,
Certification: CE, ISO9001, Minimum Order Quantity: 1, Price:
Negotiable, Packaging Details: Standard Wooden Box, Delivery Time:
15 Working Days, Payment Terms: Negotiable, Supply Ability: 100 Set
Per Month, Operation Weight: 275 mm, Type: Hydraulic, Noise Level:
5-10 M, Warranty: 1 Year, Operation Pressure: 110~140 Kgf/cm2.
We are a professional Hydraulic Breaker Manufacturer, specialized
in producing Hydraulic Breaker for Excavator. Our Hydraulic Rock
Breaker has a low noise level and high operation pressure, so it is
widely used in the demolition job, road construction, mining and
other areas. It is CE and ISO9001 certified, reliable and durable.
It comes with a 1-year warranty. We have competitive prices, and
offer customized services for our customers.
Support and Services:
Hydraulic Rock Breaker Technical Support and Service
We provide comprehensive technical support and service for our
Hydraulic Rock Breaker. Our experienced technicians are available
to help with troubleshooting, maintenance, repair, and replacement
of parts. We also provide ongoing maintenance and inspection
services, as well as preventative maintenance to ensure your
breaker continues to operate at its peak efficiency.
Our technical support team is available to answer any questions you
may have about your breaker, and can provide advice on the best way
to maintain, repair, and troubleshoot it. We also provide on-site
training for our customers on how to properly use and maintain
their Hydraulic Rock Breaker.
At Hydraulic Rock Breaker, we understand that downtime can be
costly. That’s why we provide fast, reliable, and cost-effective
service and support. Our team of experts is available 24/7 to help
you get the most out of your breaker.
FAQ:
Q1. What is the brand name of the Hydraulic Rock Breaker?
A1. The brand name of the Hydraulic Rock Breaker is DONSAN.
Q2. What is the model number of the Hydraulic Rock Breaker?
A2. The model number of the Hydraulic Rock Breaker is DSB135.
Q3. Where is the Hydraulic Rock Breaker manufactured?
A3. The Hydraulic Rock Breaker is manufactured in China.
Q4. Does the Hydraulic Rock Breaker have any certifications?
A4. Yes, the Hydraulic Rock Breaker has certifications of CE and
ISO 9001.
Q5. How many Hydraulic Rock Breakers can be supplied per month?
A5. The supply ability of the Hydraulic Rock Breaker is 100 sets
per month.
