Optimize Productivity With Hydraulic Rock Breaker - Operation
Pressure 160-180 Kgf/M2
About Us:
Donsang Machinery Co.,Ltd was found in 2012, located in Suzhou, a
beautiful garden city which is nearby the several sea port like
Shanghai ,Ningbo, Taicang. Over the decades of effort by the group,
the branch offices was established now in UAE and North America.
The company its serviced the hydraulic breaker as the start and now
covered all kinds of excavator attachments for the mining
,construction, recycling, tunnel , underwater , farming, army work
etc., industries. From the small carrier like BOBCAT to the giant
machine like the mining excavators of different brads.
6S management of the factory, fully certificated of the products,
with those high standard quality product ,the efficient team work
and reasonable price terms that there are more than 43 countries
valued clients are having the long-term relationship.
Donsang Machinery Co.,Ltd wish to provide more valuable concept and
actions to our partners so that your every words or questions are
important for
Product Description:
Our Hydraulic Hammer Breaker is a reliable breaking rock hammer
that is specifically designed to break tough rocks into smaller
pieces. Built with a tough chisel length of 1300 mm and a powerful
impact rate of 380-480 BPM, this breaker hammer is capable of
breaking even the hardest rocks. With a chisel weight of 170kg, it
is capable of delivering the required force for effective breaking.
Not to mention, it also comes with a one-year warranty. This
Hydraulic Hammer Breaker is the perfect addition to any toolbox and
can help you quickly break rocks into smaller, more manageable
sizes. Whether you are a professional or an amateur, you can rely
on our Hydraulic Hammer Breaker to get the job done quickly and
efficiently.
Our All Models Data
| Item | Unit | DSB53 | DSB68 | DSB75 | DSB85 | DSB100 | DSB135 | DSB140 | DSB150 | DSB155 | DSB165 | DSB175 | DSB180 |
Total Length
(WITH MOUNT CAP& TOOL) | SIDE TYPE | mm | 1,140 | 1,330 | 1,699 | 1,767 | 1,939 | 2,289 | 2,414 | 2,603 | 2,776 | 2,919 | 3,189 | 3,253 |
| OPEN TYPE | mm | 1,372 | 1,641 | 1,719 | 2,160 | 2,339 | 2,719 | 3,030 | 2,904 | 3,119 | 3,359 | 3,617 | 3,753 |
| BOX TYPE | mm | 1,400 | 1,658 | 1,741 | 2,200 | 2,400 | 2,766 | 3,075 | 3,075 | 3,250 | 3,450 | 3,711 | 3,760 |
Operation Weight
(WITH TOOL) | SIDE TYPE | kg | 137 | 281 | 398 | 618 | 845 | 1,605 | 1,812 | 2,530 | 2,752 | 3,189 | 4,055 | 4,586 |
| OPEN TYPE | kg | 132 | 275 | 390 | 604 | 920 | 1,784 | 1,975 | 2,750 | 2,818 | 3,514 | 4,370 | 4,600 |
| BOX TYPE | kg | 161 | 348 | 456 | 675 | 978 | 1,942 | 2,174 | 2,895 | 2,906 | 3,586 | 4,480 | 4,658 |
| Operation Pressure | kgf/cm2 | 90~120 | 110~140 | 120~150 | 130~160 | 140~170 | 160~180 | 160~180 | 160~180 | 160~180 | 160~180 | 160~200 | 180~220 |
| psi | 1,280~1,706 | 1,564~1,990 | 1,706~2,133 | 1,706~2,133 | 1,990~2,417 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,559~3,128 |
| Oil Flow | l/min | 25~45 | 40~70 | 50~90 | 60~100 | 80~120 | 120~150 | 120~150 | 170~240 | 170~240 | 190~250 | 220~260 | 220~260 |
| gpm | 6.6~11.9 | 7.9~13.2 | 13.2~23.8 | 15.8~26.4 | 21.1~31.7 | 31.7~39.6 | 31.7~39.6 | 44.9~63.4 | 44.9~63.4 | 50.1~66.0 | 58.1~76.5 | 58.1~76.5 |
| Impact Rate | bpm | 550~1000 | 450~950 | 400~900 | 400~800 | 450~630 | 350~500 | 250~400 | 380~480 | 320~450 | 280~370 | 240~320 | 210~300 |
| Nitrogen | bar | 14-17 | 14-17 | 14-17 | 14-17 | 14-17 | 14-17 | 14-17 | 18-22 | 17-20 | 17-20 | 22-25 | 22-25 |
| Chisel Diameter | mm | 53 | 68 | 75 | 85 | 100 | 135 | 140 | 150 | 155 | 165 | 175 | 185 |
| inch | 2.08 | 2.67 | 2.95 | 3.34 | 3.93 | 5.31 | 5.51 | 5.9 | 6.11 | 6.48 | 6.88 | 7.27 |
| Chisel Length | mm | 550 | 700 | 750 | 850 | 1,000 | 1,200 | 1,200 | 1,300 | 1,400 | 1,400 | 1,500 | 1,600 |
| Chisel Weight | kg | 9 | 18 | 29 | 32 | 57 | 121 | 137 | 170 | 193 | 227 | 272 | 320 |
| Hose Size | mm | 13 | 13 | 13 | 19 | 19 | 25 | 25 | 25 | 32 | 32 | 32 | 32 |
| inch | PF1/2'' | PF1/2'' | PF1/2'' | PF3/4'' | PF3/4'' | PF1'' | PF1'' | PF1'' | PF1-1/4'' | PF1-1/4'' | PF1-1/4'' | PF1-1/4'' |
| Noise Level | m | 4/8 | 5/10 | 6/12 | 6/12 | 7/14 | 16-22 | 16-22 | 26-35 | 26-35 | 35-40 | 38-45 | 42-48 |
| Suitable Exca | ton | 2.1~4.0 | 4.8~8.0 | 6.0~9.0 | 8.0~12.5 | 12~15 | 20~26 | 22~27 | 25-32 | 26~35 | 30~42 | 35~45 | 45~50 |
| Impact Force | j | 355 | 560 | 790 | 1320 | 1980 | 3450 | 3720 | 5250 | 5750 | 7040 | 14800 | 17550 |
Features:
- Excavator Hydraulic Breaker: Hydraulic Hammer Breaker
- Oil Flow: 170 - 240 L/Min
- Impact Force: 5250 J
- Hose Size: 25 Mm
- Chisel Weight: 170 Kg
- Warranty: 1 Year
Technical Parameters:
| Parameter | Value |
|---|
| Product Name | Hydraulic Hammer Breaker |
| Warranty | 1 Year |
| Oil Flow | 170 - 240 L/Min |
| Impact Rate | 380 - 480 Bpm |
| Hose Size | 25 Mm |
| Chisel Weight | 170 Kg |
| Operation Pressure | 160 - 180 Kgf/m2 |
| Suitable Excavator | 25 - 32 Ton |
| Chisel Length | 1300 Mm |
| Nitrogen | 18 - 22 Bar |
| Chisel Diameter | 150 Mm |
Applications:
DONSANG DSB150 Hydraulic Hammer Breaker
The DONSANG DSB150 Hydraulic Hammer Breaker is an ideal tool for
breaking through tough surfaces, such as concrete and asphalt. This
powerful breaker features a powerful 26-35 M noise level, 25 Mm
hose size, 1-year warranty, 2904 Mm total length (with mount cap
and tool), and 1300 Mm chisel length.
This hydraulic breaker hammer is suitable for a variety of
applications, such as demolition, trenching, foundation drilling,
road repair, and many more. With its heavy-duty construction and
advanced technology, the DONSANG DSB150 Hydraulic Hammer Breaker is
a reliable and efficient tool for all your heavy-duty projects.
The DONSANG DSB150 Hydraulic Hammer Breaker is designed for maximum
efficiency and safety. With its state-of-the-art technology, this
breaker is capable of delivering powerful results with minimal
effort. It is also easy to operate and maintain, making it an ideal
choice for any professional contractor or DIY enthusiast.
The DONSANG DSB150 Hydraulic Hammer Breaker is a reliable and
efficient tool for all your heavy-duty projects. It is perfect for
breaking through tough surfaces, such as concrete and asphalt. With
its robust construction, advanced technology, and superior
performance, the DONSANG DSB150 Hydraulic Hammer Breaker is the
perfect choice for all your hydraulic breaker tools and needs.
Customization:
Customize your Hydraulic Breaker Hammer with DONSANG! The DSB150 is a powerful and reliable hydraulic breaker hammer made with a
hose size of 25 mm, oil flow of 170 - 240 L/Min, nitrogen of 18 -
22 Bar, and a chisel weight of 170 Kg.
Our Hydraulic Breaker is the perfect solution for your demolition needs, and is sure to
meet all of your expectations. We know that quality and
dependability is important, so we use only the best materials and
components to ensure that you're getting the best product for your
money.
Choose DONSANG for all of your Breaker Hammer needs! Our Hydraulic Hammer Breaker is the perfect tool to get the job done quickly and efficiently.
Support and Services:
Technical Support & Service for Hydraulic Hammer Breakers
- We provide a comprehensive range of services for all Hydraulic
Hammer Breakers.
- We offer a wide range of services including installation,
maintenance, repair, and replacement of parts.
- Our experienced technicians are available 24/7 to provide you with
the best possible customer service.
- We offer free technical advice and support to ensure that your
Hydraulic Hammer Breaker is operating at its best.
- Our experienced team will be able to assess the situation and
provide guidance and advice on the best course of action.
- We will ensure that your Hydraulic Hammer Breaker is running
smoothly and efficiently.
FAQ:
- Q: What is the brand name of the Hydraulic Hammer Breaker?
A: The brand name of the Hydraulic Hammer Breaker is DONSANG. - Q: What is the model number of the Hydraulic Hammer Breaker?
A: The model number of the Hydraulic Hammer Breaker is DSB150. - Q: Where is the Hydraulic Hammer Breaker made?
A: The Hydraulic Hammer Breaker is made in China. - Q: What is the purpose of the Hydraulic Hammer Breaker?
A: The Hydraulic Hammer Breaker is designed to break hard substances
such as rocks and concrete. - Q: What are the advantages of the Hydraulic Hammer Breaker?
A: The Hydraulic Hammer Breaker is a highly efficient and versatile
tool. It has a high impact force and is capable of breaking even
the toughest materials. It also has a low vibration level, making
it safe and comfortable to use.
