Soosan Series Manufacturer Hydraulic Rock Breaker DSB68 For Sale
Suitable 4 Tons - 8 Tons Excavator For Breaking Rock
About Us
Donsang Machinery Co.,Ltd was found in 2012, located in Suzhou, a beautiful garden city
which is nearby the several sea port like Shanghai ,Ningbo,
Taicang. Over the decades of effort by the group, the branch
offices was established now in UAE and North America.
The company its serviced the hydraulic breaker as the start and now
covered all kinds of excavator attachments for the mining ,construction, recycling, tunnel , underwater , farming,
army work etc., industries. From the small carrier like BOBCAT to the giant
machine like the mining excavators of different brads.
6S management of the factory, fully certificated of the products,
with those high standard quality product ,the efficient team work
and reasonable price terms that there are more than 43 countries
valued clients are having the long-term relationship.
Donsang Machinery Co.,Ltd wish to provide more valuable concept and
actions to our partners so that your every words or questions are
important for us.Looking forward to hear from you.
Product Description:
Hydraulic Rock Breaker is an efficient tool for breaking rocks,
concrete or other materials. It is powered by a hydraulic pump
system, and it is used in a variety of industries such as
construction, mining, quarrying, and demolition. It has an impact
rate of 450 to 950 BPM, with an impact force of 560 J, and it
requires 40 to 70 L/min of oil flow. The rock breaker is suitable
for use with a backhoe loader for hydraulic breaker hammer
applications. It is also compact and lightweight, making it easy to
move around on the job site. The hydraulic rock breaker comes with
a 1-year warranty, ensuring your investment is protected and your
job is done right.
Features:
- Hydraulic Breaker for Excavator - Hydraulic Rock Breaker
- Operation Pressure: 110~140 Kgf/cm2
- Warranty: 1 Year
- Impact Force: 560 J
- Color: White, Blue, Customize
- Chisel Diameter: 68 Mm
Technical Parameters:
| Parameter | Value |
|---|
| Color | White, Blue, Customized |
| Noise Level | 5-10 M |
| Type | Open , Box , SIde |
| Operation Weight | 275 Mm |
| Impact Force | 560 J |
| Model | Open Type |
| Warranty | 1 Year |
| Operation Pressure | 110~140 Kgf/cm2 |
| Chisel Length | 700 Mm |
| Chisel Diameter | 68 Mm |
Our All Models Data:
| Item | Unit | DSB53 | DSB68 | DSB75 | DSB85 | DSB100 | DSB135 | DSB140 | DSB150 | DSB155 | DSB165 | DSB175 | DSB180 |
Total Length
(WITH MOUNT CAP& TOOL) | SIDE TYPE | mm | 1,140 | 1,330 | 1,699 | 1,767 | 1,939 | 2,289 | 2,414 | 2,603 | 2,776 | 2,919 | 3,189 | 3,253 |
| OPEN TYPE | mm | 1,372 | 1,641 | 1,719 | 2,160 | 2,339 | 2,719 | 3,030 | 2,904 | 3,119 | 3,359 | 3,617 | 3,753 |
| BOX TYPE | mm | 1,400 | 1,658 | 1,741 | 2,200 | 2,400 | 2,766 | 3,075 | 3,075 | 3,250 | 3,450 | 3,711 | 3,760 |
Operation Weight
(WITH TOOL) | SIDE TYPE | kg | 137 | 281 | 398 | 618 | 845 | 1,605 | 1,812 | 2,530 | 2,752 | 3,189 | 4,055 | 4,586 |
| OPEN TYPE | kg | 132 | 275 | 390 | 604 | 920 | 1,784 | 1,975 | 2,750 | 2,818 | 3,514 | 4,370 | 4,600 |
| BOX TYPE | kg | 161 | 348 | 456 | 675 | 978 | 1,942 | 2,174 | 2,895 | 2,906 | 3,586 | 4,480 | 4,658 |
| Operation Pressure | kgf/cm2 | 90~120 | 110~140 | 120~150 | 130~160 | 140~170 | 160~180 | 160~180 | 160~180 | 160~180 | 160~180 | 160~200 | 180~220 |
| psi | 1,280~1,706 | 1,564~1,990 | 1,706~2,133 | 1,706~2,133 | 1,990~2,417 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,275~2,559 | 2,559~3,128 |
| Oil Flow | l/min | 25~45 | 40~70 | 50~90 | 60~100 | 80~120 | 120~150 | 120~150 | 170~240 | 170~240 | 190~250 | 220~260 | 220~260 |
| gpm | 6.6~11.9 | 7.9~13.2 | 13.2~23.8 | 15.8~26.4 | 21.1~31.7 | 31.7~39.6 | 31.7~39.6 | 44.9~63.4 | 44.9~63.4 | 50.1~66.0 | 58.1~76.5 | 58.1~76.5 |
| Impact Rate | bpm | 550~1000 | 450~950 | 400~900 | 400~800 | 450~630 | 350~500 | 250~400 | 380~480 | 320~450 | 280~370 | 240~320 | 210~300 |
| Nitrogen | bar | 14-17 | 14-17 | 14-17 | 14-17 | 14-17 | 14-17 | 14-17 | 18-22 | 17-20 | 17-20 | 22-25 | 22-25 |
| Chisel Diameter | mm | 53 | 68 | 75 | 85 | 100 | 135 | 140 | 150 | 155 | 165 | 175 | 185 |
| inch | 2.08 | 2.67 | 2.95 | 3.34 | 3.93 | 5.31 | 5.51 | 5.9 | 6.11 | 6.48 | 6.88 | 7.27 |
| Chisel Length | mm | 550 | 700 | 750 | 850 | 1,000 | 1,200 | 1,200 | 1,300 | 1,400 | 1,400 | 1,500 | 1,600 |
| Chisel Weight | kg | 9 | 18 | 29 | 32 | 57 | 121 | 137 | 170 | 193 | 227 | 272 | 320 |
| Hose Size | mm | 13 | 13 | 13 | 19 | 19 | 25 | 25 | 25 | 32 | 32 | 32 | 32 |
| inch | PF1/2'' | PF1/2'' | PF1/2'' | PF3/4'' | PF3/4'' | PF1'' | PF1'' | PF1'' | PF1-1/4'' | PF1-1/4'' | PF1-1/4'' | PF1-1/4'' |
| Noise Level | m | 4/8 | 5/10 | 6/12 | 6/12 | 7/14 | 16-22 | 16-22 | 26-35 | 26-35 | 35-40 | 38-45 | 42-48 |
| Suitable Exca | ton | 2.1~4.0 | 4.8~8.0 | 6.0~9.0 | 8.0~12.5 | 12~15 | 20~26 | 22~27 | 25-32 | 26~35 | 30~42 | 35~45 | 36~45 |
| Impact Force | j | 355 | 560 | 790 | 1320 | 1980 | 3450 | 3720 | 5250 | 5750 | 7040 | 14800 | 17550
|
Hydraulic Rock Breaker – DonSang DSB68
The DonSang DSB68 Hydraulic Rock Breaker is a powerful and reliable
hydraulic breaker for excavators. It is made in China and certified
to CE and ISO 9001 standards. The breaker has an operation weight
of 275 mm, a hose size of PF1/2'' inch and an operation pressure of
110~140 kgf/cm2. It is ideal for breaking up rocks and concrete and
is suitable for a variety of applications, such as mining,
quarrying, demolitions, and road works. It is also perfect for
digging, trenching, and digging in hard surfaces. The package
includes a standard wooden box and delivery can be arranged within
15 working days. The price is negotiable and the supply ability is
100 sets per month.
At DonSang, our rock breakers are designed to be reliable and
powerful. Our dedicated team of engineers and technicians use the
latest technology to ensure that our products meet the highest
standards of safety and performance. We are committed to providing
our customers with the best possible solutions for their needs.
If you’re looking for a reliable and powerful hydraulic rock
breaker for your excavator, then look no further than the DonSang
DSB135. It is perfect for demolition, road works, and mining
applications. With its CE and ISO 9001 certification, you can be
sure that you’re investing in a quality product that will stand the
test of time.
Support and Services:
Technical Support and Service for Hydraulic Rock Breaker
Our technical support and service for Hydraulic Rock Breaker is
designed to ensure a successful operation and increase the
longevity of your machine.
Pre-Sales Support
We provide comprehensive pre-sales support, from product selection
to personalized advice on finding the best solution for your needs.
Installation and Commissioning
We offer professional, on-site installation and commissioning
services, to ensure that your Hydraulic Rock Breaker is up and
running as soon as possible.
Packing and Shipping:
Hydraulic Rock Breaker Packaging and Shipping:
- The rock breakers are packaged in sturdy, safe and durable
cardboard boxes.
- The boxes are then placed in a wooden container to avoid any
possible damage.
- The packages are labeled with the necessary information such as
product name, delivery address, date of delivery and other details.
- The packages are then shipped via air, sea or land, depending on
the destination.
